長壽命微動開關

特性
結構緊湊
快速動作，靈敏度高，工作行程小
長壽命微動開關，可靠性高
多種連接端子和不同長度外形杠杆
規格
UL61058 : 10.1GP/10.1RA 125VAC, 5GP/5RA 250VAC T105/T65 μ 10000 次 IP30; 6.1GP/6.1RA 125VAC, 3GP/3RA 250VAC 1/3HP 250VAC T105/T65 μ 10000 次 IP30
UL1054 : 10.1A 125VAC, 5A 250VAC T65 6000 次;6A 125VAC, 3A 250VAC, 1/3hp 250VAC T65 6000 次
ENEC/CQC : 8(3)A/8(2)A/3(3)A 250VAC T125/T85 μ 10000 次; 3A 250VAC T125/T85 μ 50000 次 IP30
絕緣阻抗 : ≥ 50MΩ
接觸阻抗 : ≤ 50mΩ

產品種類

零件編號類型電流電壓電路端子類型認證
DMB-1101-B-0AB11-01R微動開關0.1A30VDCNOSolderingUL1054, ENEC
DMB-1101-B-AAA12-01R微動開關0.1A30VDCNOSolderingUL1054, ENEC
DMB-1104-A-AAA31-01R微動開關4A, 3(3)A24VDC, 250VACNCSolderingUL1054, ENEC
DMB-1106-B-0AA11-02R微動開關6A, 3A, 1/3HP125VAC, 250VACNOSolderingUL1054
DMB-1106-B-0AA51-01R微動開關6GP, 3GP, 1/3HP, 3(3)A125VAC, 250VACNOSolderingUL1054, ENEC
DMB-1106-B-0AA51-03R微動開關6GP, 3GP, 3(3)A, 1/3HP125VAC, 250VACNOSolderingUL61058, ENEC, CQC
DMB-1106-B-AAA52-01R微動開關6GP, 3GP, 3(3)A, 1/3HP125VAC, 250VACNOSolderingUL61058, ENEC
DMB-1106-B-BAA13-02R微動開關6A, 3A, 1/3HP125VAC, 250VACNOSolderingUL1054
DMB-1106-B-DAA35-01R微動開關6A, 3A, 1/3HP, 3(3)A125VAC, 250VACNOSolderingUL1054, ENEC
DMB-1110-A微動開關10.1A, 5A, 3A125VAC, 250VACNOSolderingUL1054, ENEC
DMB-1110-A-0AA31-02R微動開關3(3)A, 5A, 10.1A125VAC, 250VACNCSolderingUL1054, ENEC
DMB-1110-A-0AA31-03R微動開關10.1A, 5A, 3(3)A125VAC, 250VACNCSolderingUL1054, ENEC
DMB-1110-B-0AA31-01B微動開關10.1A, 5A, 3(3)A125VAC, 250VACNOSolderingUL1054, ENEC, CQC
DMB-1110-B-0AA31-03R微動開關10.1A, 5A, 3(3)A125VAC, 250VACNOSolderingUL1054, ENEC
DMB-1110-B-0AA31-05R微動開關10.1A, 5A, 3A125VAC, 250VACNOSolderingUL1054, ENEC
DMB-1110-B-0AA31-06R微動開關10.1A, 5A, 3(3)A125VAC, 250VACNOSolderingUL1054, ENEC
DMB-1110-B-0AA31-07R微動開關10.1A, 5A, 3(3)A125VAC, 250VACNOSolderingUL1054, ENEC, CQC
DMB-1110-B-0AD31-01R微動開關10.1A, 5A, 3(3)A125VAC, 250VACNOSolderingUL1054, ENEC
DMB-1110-B-0AG31-01R微動開關10.1A, 5A, 3A125VAC, 250VACNOQCUL1054, ENEC
DMB-1110-B-0CA31-01R微動開關10.1A, 5A, 3(3)A125VAC, 250VACNOSolderingUL1054, ENEC
DMB-1110-B-AAA22-02B微動開關3(3)A250VACNOSolderingENEC
DMB-1110-B-AAA32-01R微動開關10.1A, 5A, 3(3)A125VAC, 250VACNOSolderingUL1054, ENEC
DMB-1110-B-AAA32-08R微動開關10.1A, 5A, 3(3)A125VAC, 250VACNOSolderingUL1054, ENEC
DMB-1110-B-AAA32-09R微動開關10.1A, 5A, 3A125VAC, 250VACNOSolderingUL1054, ENEC, CQC
DMB-1110-B-AAA72-01R微動開關10.1A, 5A, 3(3)A125VAC, 250VACNOSolderingUL1054, ENEC, CQC
DMB-1110-B-AAG32-01R微動開關10.1A, 5A, 3A125VAC, 250VACNOQCUL1054, ENEC, CQC
DMB-1110-B-AAG72-01B微動開關10.1A, 5A, 3(3)A125VAC, 250VACNOSolderingUL1054, CQC
DMB-1110-B-CAA32-01R微動開關10.1A, 5A, 3(3)A125VAC, 250VACNOSolderingUL1054, ENEC
DMB-1110-B-HAA32-02R微動開關10.1A, 5A, 3(3)A125VAC, 250VACNOSolderingUL1054, ENEC
DMB-1110-B-HAA32-03R微動開關10.1A, 5A, 3A125VAC, 250VACNOSolderingUL1054, ENEC
DMB-1116-A-0AB31-02R微動開關10.1A, 5A, 8(2)A125VAC, 250VACNCSolderingUL1054, ENEC
DMB-1116-A-0BB31-02R微動開關10.1A, 5A, 8(2)A125VAC, 250VACNCSolderingUL1054, ENEC
DMB-1116-A-0BB31-03R微動開關8(2)A, 5A, 10.1A125VAC, 250VACNCSolderingUL1054, ENEC, CQC
DMB-1116-B-0AB31-02R微動開關8(2)A, 5A, 10.1A125VAC, 250VACNOSolderingUL1054, ENEC
DMB-1201-C-CAB12-01R微動開關0.1A30VDCNC.+NO.SolderingUL1054, ENEC
DMB-1204-C-BAA31-01R微動開關4A, 3(3)A24Vdc, 250VacNC.+NO.SolderingUL1054, ENEC
DMB-1206-C-0AA11-02R微動開關6A, 3A, 1/3HP125VAC, 250VACNC.+NO.SolderingUL1054
DMB-1206-C-0AA11-04R微動開關6A, 3A, 1/3HP125VAC, 250VACNC.+NO.SolderingUL1054
DMB-1206-C-0AA31-01R微動開關6A, 3A, 1/3HP, 3(3)A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC
DMB-1206-C-0AA31-02R微動開關6A, 3A, 1/3HP, 3(3)A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC
DMB-1206-C-AAA12-02R微動開關6A, 3A, 1/3HP125VAC, 250VACNC.+NO.SolderingUL1054, CSA
DMB-1206-C-AAA12-03R微動開關6A, 3A, 1/3HP125VAC, 250VACNC.+NO.SolderingUL1054, CSA
DMB-1206-C-AAA12-05R微動開關6A, 3A, 1/3HP125VAC, 250VACNC.+NO.SolderingUL1054, CSA
DMB-1206-C-AAA12-06R微動開關6A, 3A, 1/3HP125VAC, 250VACNC.+NO.SolderingUL1054, CSA
DMB-1206-C-AAA12-07R微動開關6A, 3A, 1/3HP125VAC, 250VACNC.+NO.SolderingUL1054, CSA
DMB-1206-C-AAA42-01R微動開關6GP, 3GP, 1/3HP125VAC, 250VACNC.+NO.SolderingUL61058
DMB-1206-C-AAD32-01R微動開關6A, 3A, 1/3HP, 3(3)A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC
DMB-1206-C-CAA12-01R微動開關6A, 3A, 1/3HP125VAC, 250VACNC.+NO.SolderingUL1054, CSA
DMB-1210-C-0AA31-02R微動開關3(3)A, 5A, 10.1A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC
DMB-1210-C-0AA31-03R微動開關3(3)A, 5A, 10.1A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC
DMB-1210-C-0AA31-05R微動開關3(3)A, 5A, 10.1A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC
DMB-1210-C-0AA31-11R微動開關3(3)A, 5A, 10.1A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC
DMB-1210-C-0AA31-12R微動開關3(3)A, 5A, 10.1A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC, CQC
DMB-1210-C-0AA31-13R微動開關3(3)A, 5A, 10.1A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC
DMB-1210-C-0AA71-01R微動開關3A, 5A, 10.1A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC, CQC, CSA
DMB-1210-C-0AA71-02R微動開關3A, 5A, 10.1A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC, CQC
DMB-1210-C-0AD71-01R微動開關10.1A, 5A, 3A125VAC, 250VACNC.+NO.PCBUL1054, ENEC, CQC
DMB-1210-C-0AE11-02R微動開關10.1GP, 5GP125VAC, 250VACNC.+NO.PCBUL61058
DMB-1210-C-0CA31-05R微動開關10.1A, 5A, 3(3)A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC
DMB-1210-C-0CA31-07R微動開關3(3)A, 5A, 10.1A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC
DMB-1210-C-AAA32-01R微動開關3(3)A, 5A, 10.1A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC
DMB-1210-C-AAA32-02R微動開關3(3)A, 5A, 10.1A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC
DMB-1210-C-AAA32-03R微動開關3(3)A, 5A, 10.1A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC
DMB-1210-C-AAA32-07R微動開關3A, 5A, 10.1A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC, CQC
DMB-1210-C-AAA32-08R微動開關3(3)A, 5A, 10.1A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC
DMB-1210-C-AAA32-09R微動開關3(3)A, 5A, 10.1A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC
DMB-1210-C-AAD22-01B微動開關3(3)A250VACNC.+NO.PCBENEC
DMB-1210-C-ADA32-01R微動開關3(3)A, 5A, 10.1A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC
DMB-1210-C-BAA33-04R微動開關3(3)A, 5A, 10.1A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC
DMB-1210-C-CAA34-02R微動開關10.1A, 5A, 3(3)A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC
DMB-1210-C-CAA34-04R微動開關10.1A, 5A, 3(3)A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC
DMB-1210-C-CAE34-01R微動開關3(3)A, 5A, 10.1A125VAC, 250VACNC.+NO.PCBUL1054, ENEC
DMB-1210-C-KAG12-03R微動開關5A, 10.1A125VAC, 250VACNC.+NO.QCUL1054
DMB-1210X-C-BAA33-01R微動開關10.1A, 5A, 3(3)A125VAC, 250VACNC.+NO.Lead WireUL1054, ENEC
DMB-1216-C-0AB61-01R微動開關8(3)A, 5GP, 10.1GP125VAC, 250VACNC.+NO.SolderingUL61058, ENEC, CQC
DMB-1216-C-0AB71-01R微動開關8(2)A, 5A, 10.1A125VAC, 250VACNC.+NO.SolderingUL1054, ENEC, CQC
Switches125Vac, 250Vac10.1GP/RA, 5GP/RA 6.1GP/6.1RA, 3GP/3RA, 1/3HP, 10.1A, 6A 3A, 8(3)A/8(2)A/3(3)AUL, ENEC
